ZY-HHE12 Support IR ,RS232 & Loop Out H.264 HDMI Over TCP IP Extender 120m By RJ45 Cat5e/6 Cable 1080P HDMI Transmitter Receiver

ZY-HHE12,H.264 HDMI over IP extender provides extension of HDMI signals up to 120 meters by a single cat5e/6 cable at resolution up to 1080P@60HZ. It applies advanced video decode H.264 that is with excellent image processing and transmission capacity, offering more fluent and steady signal transmission. It supports point-to-point and one-to-many connection system, and provides RS232 communication port.

  • HDMI 1.3, HDCP 1.2 version;
  • Support resolution up to 1920*1080@60Hz;
  • The output image quality is the most vivid among compressed extenders. Very clear characters, fit use in class room and meeting room;
  • Transmit HDMI signal up to 120m over single UTP cat6 cable, 100m over UTP cat5e cable, 85m over UTP cat5 cable;
  • Good anti-interference performance, strong adaptive abilityfor long time operating and use in high temperature;
  • Audio: sampling rate: 32kHz, 44.1kHz and 48kHz ;
  • Audio Format: DTS-HD/Dolby-true HD/LPCM7.1/DTS/DSD ;
  • Low bandwidth occupation: 10Mbps;
  • Transmitter supports one channel HDMI output(HDMI loop out);
  • Support IR 20~60KHz remote control;
  • Support RS232 serial port for control via PC;
  • Support one to one application and one to many application with Ethernet switch/Router;
  • Support over TCP/IP and H.264 technology;
  • Little influence to the internet usage when it is connected to the switch;
  • Easy to install, plug and play ;
  • Built-in automatic adjustment system, make the image smooth, clear and stable;
  • Built-in ESD protection.

Parameter Description
Video Standards HDMI 1.3; HDCP 1.2
Maximum pixel clock 165MHz
Maximum data rate 6.75Gbps
Resolution Max: 1920X1080p@60Hz
Connector HDMI-A
IR Interface 3.5mm earphone seat
IR Signal direction Unidirectional
Signal type Digital
IR frequency 20~60KHz
Ethernet Interface RJ45/IEEE-568B
Transmission distance CAT6—–120m

CAT5e—100m

CAT5—–85m
Power supply The power adapter: DC 5~12V/2A
Power dissipation MAX 8W
Temperature Operating: -5 ~ +70
Humidity Operating: 5% ~ 90%
Dimension 78*51*25mm
The warranty 2 year free warranty
